Gail India Limited

Gail HDPE G‑Lene E45A003 is a high‑density polyethylene (HDPE) resin from GAIL (India) Limited designed specifically for blown film extrusion as a blending component. GAIL positions this grade for use in blend with LDPE/LLDPE to produce co‑extruded laminated and non‑laminated films for a wide range of packaging and industrial film applications. As an HDPE, E45A003 belongs to the linear polyethylene family, typically chosen when film converters need to add stiffness, strength, and load‑carrying capability compared to LDPE/LLDPE‑only structures. What makes E45A003 distinct is its low flow (low MFI) profile, which supports film strength and stiffness contribution while still being described as offering excellent processability with moderate stiffness when used in properly engineered blends. For standards‑driven procurement, the manufacturer’s sheet states that E45A003 conforms to natural‑resin designation IS 7328‑3B‑FB‑DXDA of IS 7328:2020 (certificate available on request). This is useful when film producers must document resin designation alignment for internal QA or customer qualification.

Technical insights

Typical datasheet‑style properties

• Melt Flow Index (MFI, I2; 190°C/2.16 kg): 6 g/10 min (ASTM D1238)
• Density (23°C): 945 g/cm³ (ASTM D1505)
• Tensile strength at break (MD/TD): 400/350 kg/cm² (ASTM D882)
• Elongation at break (MD/TD): 750/900% (ASTM D882)
• Tear strength (MD/TD): 3/4 g (ASTM D1922)

What these properties indicate for film performance

MFI 0.6 (low flow): A low MFI HDPE typically contributes to higher melt strength and improved film strength/stiffness versus higher‑MFI film grades. In practice, this can help converters build tougher structures, but it also means processing and blend design matter to maintain stable bubble and output. Density 0.945: This density sits in the HDPE range and generally correlates with higher stiffness and better barrier contribution than lower‑density polyethylenes. In multilayer films, it’s often used to improve “body” and handling without over‑softening. MD/TD tensile and elongation: The tensile and elongation values (noted as typical on 40–50 µm blown films) indicate a balance of strength and ductility. This is relevant for packaging films that must resist tearing during handling while still stretching rather than cracking. MD/TD tear: Tear values highlight directional behaviour common in blown films. This is one reason E45A003 is positioned as a blending/co‑ex component—layer design and blend ratios are used to tune tear propagation and toughness. Important note on “typical” data: These are typical guidance values from the manufacturer sheet (not guaranteed limits). Final properties depend heavily on blend ratio, film thickness, blow‑up ratio, frost line height, and layer structure.

Applications

Co‑extruded packaging films (laminated and non‑laminated)

E45A003 is recommended for co‑extruded blown film structures where converters blend HDPE with LDPE/LLDPE to balance stiffness, toughness, sealability, and process stability. It’s relevant for packaging films where better “hand feel” and strength are needed without losing the processing advantages of LD/LLDPE.

Industrial wrap and protective films

For industrial wrapping films and protective packaging, adding a low‑flow HDPE component can improve load‑holding and puncture resistance in the final structure. E45A003 is typically considered when the film must stay firm during wrapping, stacking, and transit.

Bag and liner structures (multi‑layer)

In bags, liners, and sack‑type films, E45A003 can be used as part of a multilayer recipe to increase stiffness and strength while LD/LLDPE layers contribute seal performance and toughness. This is especially useful when converters need a more rigid film without moving to a full HDPE monolayer design.

Comparable alternatives

Comparable HDPE film grades exist, but E45A003 is specifically positioned as a blown‑film blending grade for LD/LLDPE co‑extrusion.

• G‑Lene F45A003 (GAIL): Often referenced as a blown‑film HDPE grade around 45 MFI with similar density (~0.945 g/cm³). Relative to E45A003 (0.6 MFI), a lower MFI grade may contribute more stiffness/strength but can be less forgiving in processing. Use official TDS comparisons to confirm film mechanicals and intended use language.
• LLDPE blown‑film grades (e.g., G‑Lene LLDPE film grades): LLDPE‑dominant structures typically deliver better toughness and sealability, but can feel softer and less stiff. E45A003 is used when you want to “lift” stiffness/strength in a co‑ex structure while keeping LD/LLDPE benefits.
• Other supplier HDPE film components: Other manufacturers offer low‑flow HDPE film resins, but direct equivalence should only be claimed after matching MFI, density, and film mechanicals under similar test conditions (thickness, BUR, drawdown).

Common search variants

Also searched as: Gail E45A003 HDPE, E45A003 HDPE blown film, HDPE blown film granules, HDPE dana for film. Common variants/misspellings: G‑lene E45A003, E45A 003, E45A003A.

G‑Lene I50A180 is a high‑density polyethylene (HDPE) injection‑moulding grade from GAIL (India) Limited, designed for fast filling of thin‑wall household parts where surface finish and cycle time matter. In GAIL’s own technical sheet, the grade is positioned for household products such as buckets, mugs, and similar injection‑moulded items, highlighting excellent processability, low degree of warpage, and superior gloss. As a very‑high‑flow HDPE (high MFI) with high density, I50A180 is typically selected by moulders who want a practical stiffness–toughness balance for everyday domestic containers and general rigid moulded goods—especially when the mould has thin sections, long flow lengths, or needs consistent appearance across high‑volume production runs. GAIL states the resin conforms to the natural‑resin designation IS 7328‑3B‑MB‑FXDE of IS 7328:2020 (certificate available on request), which is highly relevant for moulded household product applications in India.

Technical insights (what the key properties indicate)

Flow & mould filling (MFI)

With a typical Melt Flow Index (190°C/2.16 kg) of 20 g/10 min, I50A180 sits in the very‑high‑flow injection moulding class. Practically, this supports faster filling, easier processing of thin walls, and shorter cycle times—helpful for buckets, mugs, and toy parts where productivity and finish are critical.

Stiffness & part rigidity (density and flexural modulus)

A typical density of 0.952 g/cm³ indicates a higher‑density HDPE structure that generally contributes to stiffness and dimensional stability. A flexural modulus around 9000 kg/cm² (as commonly mirrored by distributor listings) aligns with the “houseware rigidity” requirement—parts feel firm and hold shape under normal household loads.

Strength & ductility (tensile and elongation)

Typical tensile strength at yield is 230 kg/cm² with elongation at yield of 10%, and elongation at break of 400% (on compression‑moulded specimens). This combination is commonly read by moulders as “stiff enough to hold form, but not brittle,” supporting everyday handling and drops typical in domestic use.

Stress crack resistance (ESCR)

The ESCR value is listed as <10 hours (10% Igepal, ASTM D1693, F50), which signals that this is not a stress‑crack‑resistant packaging/industrial container grade. It’s better positioned as a standard household injection grade where high flow, gloss, and warpage control are prioritized over long‑term ESCR performance.

Heat performance (Vicat)

A typical Vicat softening point of 122°C helps buyers assess heat tolerance for household environments (warm water exposure, general heat near kitchens, etc.), without positioning it as a high‑temperature engineering plastic.

Processing guidance (from the datasheet)

GAIL’s processing guidance lists barrel temperature 200–280°C and mould temperature 25–40°C—useful guardrails for stable moulding, finish control, and warpage management in thin‑wall parts.

Applications (industries & use cases)

Household containers and utility items: I50A180 is commonly specified for injection‑moulded buckets, mugs, and household containers where thin walls, good surface gloss, and low warpage are important. The very‑high‑flow nature supports clean filling and consistent appearance in high‑cavity or fast‑cycle production. Toys and general rigid moulded goods: For toy components and general‑purpose rigid injection parts, moulders often need a balance of stiffness, ductility, and processability. I50A180’s typical tensile/elongation profile and high flow make it suitable where the part geometry is complex or thin, and where visual finish matters. Thin‑wall injection moulding for mass production: When the priority is productivity—short cycle times, reliable filling, and stable dimensions—very‑high‑flow HDPE grades like I50A180 are often preferred over lower‑MFI options that may offer different mechanical emphasis but can be slower to fill in thin sections.

Comparable alternatives (positioning vs similar grades)

GAIL I56A200U (similar flow class): I56A200U is often referenced as a comparable GAIL injection grade with similar high flow (commonly cited around 20 MFI) and slightly higher density positioning in some listings. Where confirmed by manufacturer sheets, moulders may compare these two for gloss/warpage behaviour and the stiffness “feel” of finished parts. Do not assume drop‑in equivalence unless the latest GAIL TDS values and IS designation match your requirement. GAIL I50A250 (higher flow): I50A250 is positioned as a higher‑flow option (commonly cited around 25 MFI). In general, higher flow can further improve thin‑wall filling and cycle time, but may shift the balance of mechanical performance depending on the exact grade design. Use manufacturer TDS comparison to validate performance targets (warpage, stiffness, impact). Lower‑MFI injection grades (e.g., crate/rigid emphasis): Compared with lower‑MFI HDPE injection grades, I50A180 is clearly positioned for thin‑wall houseware productivity and appearance (gloss, warpage control). If your application needs higher ESCR or different long‑term performance, a different HDPE family/grade selection may be more appropriate.

Common search variants

Also searched as: “Gail I50A180 HDPE”, “G‑Lene I50A180 20 MFI”, “HDPE I50A180 injection moulding”, “I50A180 HDPE dana / granules”. Common variants/misspellings: “150A180”, “I50 A180”, “G Lene I50A180”, “Glen I50A180”.

Gail HDPE G‑Lene I60A080 is a high‑density polyethylene (HDPE) resin designed for injection moulding where fast filling, clean surface finish, and consistent rigidity are required. Positioned as a high‑flow, high‑density grade, it is commonly selected for general‑purpose and industrial‑purpose crates, caps and closures, and rigid container‑type moulded parts. This grade is manufactured by GAIL (India) Limited under its G‑Lene petrochemicals portfolio. In GAIL’s own technical sheet, I60A080 is described as an injection‑moulding HDPE made using G‑Lene swing‑plant technology (Sclairtech solution and Unipol gas‑phase processes). For buyers, that translates into a resin family built for repeatable processing, high‑cycle moulding, and dependable part performance in day‑to‑day industrial handling. A key trust signal for procurement and quality teams: GAIL states that I60A080 conforms to IS 7328:2020 with natural‑resin designation IS 7328‑3‑MB‑GXDD (certificate available on request), supporting standardization for moulded product manufacturing.

Technical insights

I60A080 is typically evaluated by moulders on flow, stiffness, surface, and impact balance: Flow and cycle‑time behavior: With a typical Melt Flow Index (MFI, I2 at 190°C/2.16 kg) of 8.0 g/10 min, this is a high‑flow HDPE suited to faster filling of thin‑wall or complex‑geometry moulds (common in crates and closure designs). Higher flow often supports shorter cycle times and easier mould filling, especially when running multi‑cavity tools. Stiffness and dimensional stability: A typical density of 0.960 g/cm³ places I60A080 firmly in the high‑density class, generally associated with higher stiffness and better load‑bearing behavior in rigid parts. Combined with a typical flexural modulus of 9500 kg/cm², it is positioned for crates and rigid moulded components where shape retention matters. Strength, toughness, and handling durability: Typical tensile strength at yield of 255 kg/cm² indicates solid load resistance for everyday industrial use. Typical elongation at yield of 10% and elongation at break >350% reflect a material that can deform before failing—useful in parts that see drops, stacking, and repeated handling. Surface and heat resistance indicators: Typical Shore D hardness of 67 supports a “hard, rigid feel” expected in crates and closures. Typical Vicat softening point (10 N) of 124°C is a practical indicator for heat‑related dimensional stability (e.g., warm filling environments, storage in hot conditions), while still requiring process‑appropriate design and testing.

Applications

Injection‑moulded crates (general‑purpose and industrial)

G‑Lene I60A080 is widely positioned for injection‑moulded crates where moulders need a high‑flow HDPE that fills quickly and produces stiff, durable parts. Typical use cases include beverage crates, industrial transport crates, and handling boxes where low warpage and consistent rigidity help maintain stackability and dimensional control.

Caps and closures

For caps and closures, the grade’s high flow supports high‑cavity moulds and fast cycle times, while the high density contributes to rigidity and thread integrity. It is a practical choice for closure‑type parts where consistent mould filling and repeatable part dimensions are critical.

Rigid moulded parts (luggage shells, helmets, container‑type parts)

GAIL also positions I60A080 for rigid moulded parts such as luggage shells and helmets. In these applications, moulders often want a balance of stiffness, surface appearance, and impact tolerance—especially when parts must hold shape while still resisting cracking under handling stress.

Comparable alternatives

Comparable HDPE injection‑moulding grades exist in India, including other GAIL G‑Lene injection grades such as I60U080 (UV‑stabilized) and I62A080U. However, direct equivalence should not be assumed unless the manufacturer technical data sheets match on key parameters such as MFI (flow), density (stiffness), tensile at yield, impact (Izod), and warpage behavior under similar test methods. Positioning‑wise, I60A080 is best treated as a standard (non‑UV) high‑flow crate/cap grade. If your application involves outdoor exposure and long sunlight resistance requirements, UV‑stabilized variants may be more appropriate—validate via the specific grade’s manufacturer sheet and your part testing.

Common search variants

Also searched as: Gail HDPE I60A080, G‑Lene I60A080 granules, HDPE I60A080 injection moulding dana, I60A080 MFI 8. Common variants: I60A 080, I60A80, G Lene I60A080.

Gail HDPE G‑Lene I60U080 is a UV‑stabilized high‑density polyethylene (HDPE) resin designed for injection moulding of crates and rigid moulded parts that see outdoor exposure. It is positioned for applications like soft‑drink and milk crates, fishing crates, and helmets—where converters need high flow for fast filling, low warpage for dimensional control, and weatherability to handle sunlight‑driven ageing. This grade is manufactured by GAIL (India) Limited under the G‑Lene petrochemicals portfolio. GAIL describes I60U080 as an injection‑moulding HDPE produced via G‑Lene swing‑plant technology (Sclairtech solution and Unipol gas‑phase routes) and supplied in UV‑stabilized form (the “U” suffix). For buyers, this means a resin intended to keep parts tougher and more stable in real‑world outdoor handling—stacking, drops, moisture, and repeated sunlight exposure. For specification and QA: the GAIL technical sheet explicitly states that I60U080 conforms to IS 7328:2020 with natural‑resin designation IS 7328‑3‑MD‑GXDD (certificate available on request). This is a strong compliance anchor for moulded product raw‑material standardization.

Technical insights

I60U080 is typically evaluated by moulders on flow, stiffness/shape retention, impact balance, and outdoor durability: Flow and cycle‑time performance: With a typical Melt Flow Index (MFI, I2 at 190°C/2.16 kg) of 8.0 g/10 min, I60U080 sits in the high‑flow injection‑moulding class. High flow generally supports easier filling of thin walls, ribs, and complex crate geometries—often enabling shorter cycle times and more consistent part replication across cavities. Stiffness and stacking behavior: A typical density of 0.960 g/cm³ indicates a high‑density structure associated with higher stiffness in rigid parts. The typical flexural modulus of 9500 kg/cm² supports the grade’s positioning for crates that must hold shape under stacking and transport loads. Strength and impact balance for handling crates: Typical tensile strength at yield of 255 kg/cm² indicates solid load‑bearing capability for routine handling. Typical elongation at yield of 10% and elongation at break >350% suggest the resin can deform before failing—useful in crates and helmets that face repeated knocks. Surface hardness and heat‑softening indicator: Typical Shore D hardness of 67 aligns with the rigid feel expected in crates and protective rigid parts. Typical Vicat softening point (10 N) of 124°C is a practical indicator for resistance to softening at elevated temperatures during storage/transport. ESCR and what it means in practice: The grade includes an ESCR value (ASTM D1693, 10% Igepal, F50) reported as <24 hours in the provided inputs. ESCR is relevant when parts see detergents, surfactants, or stress + chemical exposure; for crate applications, validate ESCR needs against your end‑use environment and cleaning chemicals. UV stabilization (outdoor weatherability): UV stabilization is intended to improve resistance to sunlight‑driven degradation such as embrittlement, surface cracking, and discoloration. For beverage and dairy crates stored outdoors, this is often the key differentiator versus non‑UV injection grades.

Applications

Outdoor soft‑drink and milk crates

G‑Lene I60U080 is recommended for soft‑drink and milk crates used in outdoor distribution cycles—loading bays, open trucks, and yard storage. High flow supports high‑throughput moulding, while UV stabilization helps maintain durability and appearance over repeated sunlight exposure.

Fishing crates and outdoor handling baskets

Fishing crates and outdoor handling baskets often face wet conditions, sunlight, and rough handling. I60U080’s combination of stiffness, impact balance, and weatherability makes it a practical candidate for rigid crate designs that must stay stackable and crack‑resistant.

Helmets and rigid moulded protective parts

GAIL also positions I60U080 for helmets. In rigid protective parts, converters typically value consistent mould filling, good surface finish, and a balance of stiffness and toughness—while UV stabilization can help when products are stored or used in outdoor environments.

Comparable alternatives

Comparable HDPE injection‑moulding grades exist in India, including other GAIL G‑Lene grades such as I60A080 (non‑UV) and I62A080U (UV‑stabilized, higher stiffness). However, direct interchangeability should not be assumed unless manufacturer data sheets align on key parameters like MFI (flow), density (stiffness), tensile at yield, flexural modulus, impact (Izod), ESCR, and the presence/type of UV stabilization. Positioning‑wise, I60U080 can be treated as a UV‑stabilized version of a high‑flow crate grade: it targets outdoor‑exposed crates without fundamentally moving away from the high‑flow, production‑friendly processing window. If you need higher stiffness for stacking, a higher‑modulus UV crate grade may be evaluated; if the application is indoor, a non‑UV high‑flow grade may be sufficient—confirm via mould trials.

Common search variants

Also searched as: Gail HDPE I60U080, G‑Lene I60U080 UV stabilized, HDPE crate grade UV, I60U080 MFI 8, HDPE dana injection moulding. Common variants: I60U 080, I60U080A, G Lene I60U080, Gail I60 U080.

Gail HDPE G‑Lex B52A003 (and the related B52A003N) is a high‑density polyethylene (HDPE) blow‑moulding resin from GAIL (India) Limited developed for small‑ to medium‑size blow‑moulded containers. It is positioned for packaging that needs a dependable balance of stiffness, impact resistance, and environmental stress crack resistance (ESCR)—especially in applications where bottles are dropped, squeezed, stacked, or exposed to oils, detergents, and household/industrial chemicals. GAIL describes this grade as having good processability with a medium melt flow index, enabling stable mould filling and cycle control for everyday container formats. Across the G‑Lex HDPE family, GAIL references CX slurry process technology as a platform associated with mechanical strength, impact performance, and ESCR. For standards alignment, the datasheet notes conformance to natural‑resin designation IS 7328‑3B‑BB‑FXDA of IS 7328:2020 (polyethylene raw material for moulding/extrusion for blow‑moulded products). The resin is supplied as natural/white pellets, typically in 25 kg woven sacks, with standard storage guidance: keep material dry, store below 50 °C, and avoid contamination.

Technical insights

• Melt Flow Index (I2, 190 °C/2.16 kg): 0.42 g/10 min (typical): A medium MFI helps balance mould filling and parison control for blow moulding—supporting productivity without sacrificing container strength.
• Density (23 °C): 0.954 g/cm³ (typical): A density in this range supports stiffness and top‑load strength, which is important for stackable bottles and cans.
• Tensile strength at yield: 240 kg/cm² (typical): Indicates the resin’s ability to resist deformation under load—useful for bottles that must hold shape during handling and storage.
• Elongation at yield: 10% (typical): Suggests controlled ductility at yield; for blow‑moulded packaging, this helps balance stiffness with practical toughness.
• Flexural modulus: 10000 kg/cm² (typical): Higher modulus generally correlates with rigidity, helping containers feel firm and resist paneling.
• Izod impact strength: 120 J/m (typical): Supports drop resistance, especially relevant for edible‑oil and lube‑oil bottles that face rough handling.
• Shore D hardness: 62 (typical): Indicates surface hardness and scratch resistance—useful for consumer packaging aesthetics and handling.
• ESCR (10% Igepal): >500 hours (typical): A key selection factor for blow‑moulded containers; higher ESCR helps reduce cracking in contact with surfactants, oils, and stress‑concentrated areas (handles, corners, base).

Applications

Edible‑oil and ghee bottles (food packaging): B52A003 is positioned for edible‑oil and ghee containers where stiffness and drop resistance matter, and where packaging must hold shape during transport, stacking, and retail handling. Lube‑oil and automotive fluid containers: For lube‑oil bottles and small jerrycans, ESCR and chemical resistance become critical. This grade is relevant where containers face long storage times, temperature changes, and exposure to oils and additives. Toiletries and cosmetics bottles: In personal care packaging, converters need clean moulding, good stiffness, and impact resistance for daily‑use bottles. B52A003’s medium‑flow blow‑moulding positioning fits common toiletry formats. Pharmaceutical and healthcare packaging (non‑sterile containers): The grade is referenced for pharma‑type bottles where consistent moulding and crack resistance are important. Final suitability depends on the specific product, regulatory requirements, and the converter’s compliance program.

Comparable alternatives

B52A003 is a purpose‑built blow‑moulding HDPE grade, so comparisons should be made against other container‑grade HDPEs—not pipe or film grades.

• B52A003N: Typically treated as the closest alternative within the same family. Substitution should be validated against the latest manufacturer documentation (and COA) to confirm any stabilizer/additive differences.
• General film or pipe grades (e.g., E52A003/E52A003N, P52A003): These are positioned for different processing methods and performance targets (film/pipe). Even if some base properties look similar, they are not direct substitutes for blow‑moulded container production without trials and datasheet matching.

Procurement takeaway: treat “equivalent grade” claims as unconfirmed unless you match (1) MFI, (2) density, (3) ESCR/impact targets, and (4) the manufacturer’s intended application class (blow‑moulded containers).

Common search variants

Also searched as: HDPE blow moulding granules, bottle grade HDPE dana, edible oil bottle HDPE, lube oil container HDPE. Common variants/misspellings: B52AOO3, B52A003N, G Lex B52A003, GAIL B52A003 HDPE.

Gail HDPE G‑Lex B52A003N is a UV‑stabilized high‑density polyethylene (HDPE) blow‑moulding grade from GAIL (India) Limited. It is positioned for small‑ to medium‑size containers up to about 5 litres, especially where buyers need a dependable balance of toughness, environmental stress‑cracking resistance (ESCR), and processability. In practical packaging terms, B52A003N is selected for blow‑moulded bottles, cans and small jerrycans that must handle drop impact, longer shelf storage, and contact with oils, detergents, and cosmetic‑type formulations without premature cracking around high‑stress areas (base, handle, shoulder, neck). The “N” variant adds UV stabilization, supporting better handling and storage stability versus the non‑UV grade. As per the manufacturer’s datasheet positioning, the grade conforms to natural‑resin designation IS 7328‑3B‑BB‑FXDA of IS 7328:2020 for polyethylene used in moulding/extrusion for blow‑moulded products.

Technical insights

• Melt Flow Index (I2) ~0.42 g/10 min (190°C/2.16 kg): A medium‑flow blow‑moulding MFI that supports stable parison formation and good processability for small‑to‑mid container sizes, while still maintaining stiffness and ESCR.
• Density ~0.954 g/cm³: Typical of HDPE grades designed for higher stiffness and strength—useful for bottles that must retain shape, stack well, and resist paneling.
• Tensile strength at yield ~240 kg/cm² & elongation at yield ~10%: Indicates a strength‑first profile with controlled ductility—helpful for dimensional stability while still resisting brittle failure.
• Flexural modulus ~10000 kg/cm²: Signals higher rigidity, supporting better top‑load performance and “firm” bottle feel.
• Izod impact strength ~120 J/m: Supports toughness for handling and drop events during packing, transport and use.
• Shore D hardness ~62: A balanced surface hardness for scuff resistance and handling without becoming overly brittle.
• ESCR (10% Igepal) >500 hours: A key decision metric for detergent, toiletry, lube‑oil and chemical‑adjacent packaging—helps reduce stress‑crack risk over time.
• Vicat softening point ~123°C: Useful for understanding heat resistance during storage/handling and for setting expectations in warm environments.

Applications

Edible‑oil and ghee bottles (up to ~5 L): B52A003N is commonly specified for HDPE edible‑oil packaging where manufacturers want a stiff, tough bottle with strong ESCR to reduce cracking at the base and shoulder during filling, capping, transport and shelf life. Lube‑oil and automotive fluid containers: For lubricant packs, the combination of rigidity, impact strength and ESCR helps containers withstand handling abuse and long storage without stress‑cracking—especially important around handles and neck finishes. Toiletries and cosmetics bottles: Toiletry and cosmetic formulations can be aggressive to plastics over time. This UV‑stabilized HDPE blow‑moulding grade is used when converters need consistent bottle performance, good stiffness and better resistance to formulation‑related stress cracking. Pharmaceutical and healthcare packaging (non‑sterile bottles/containers): For pharma‑type bottles where robust handling, reliable mechanical performance and clean, consistent processing matter, B52A003N is positioned as a practical HDPE blow‑moulding option—subject to the converter’s compliance validation for the intended end use.

Comparable alternatives

• GAIL G‑Lex B52A003 (non‑UV): Closest internal alternative when UV stabilization is not required. B52A003N is typically preferred when storage/handling conditions call for added UV stability.
• Other HDPE blow‑moulding grades in India (similar class): Comparable products are generally evaluated by matching MFI (~0.42 range), density (~0.954), ESCR (>500 h), stiffness (flexural modulus), and impact. If any of these shift materially, converters may see changes in parison stability, cycle time, bottle rigidity, or stress‑crack performance.
• E52A003/E52A003N (not a direct equivalent): While sometimes discussed alongside B‑series grades in market summaries, equivalence should not be assumed unless your team matches the full TDS cluster and validates performance on your moulds and end‑use conditions.

Common search variants

Also searched as: Gail B52A003N, G‑Lex B52A003N HDPE, B52A003N dana, HDPE blow moulding granules. Common misspellings: B52AOO3N, B52A003M, Glex B52A003N.

Gail HDPE G‑Lex B63A003 is a high‑density polyethylene (HDPE) blow‑moulding grade from GAIL (India) Limited. It is positioned for medium‑size containers up to about 15 litres, mainly for foodstuffs such as edible oil and ghee, where converters need an optimized balance of toughness, stiffness, stackability, and processability. In packaging terms, B63A003 is typically chosen for rigid, stack‑stable blow‑moulded jerrycans, cans and bottles in the 5–15 L range. The grade’s higher density and stiffness profile supports containers that must hold shape under top‑load/stack load, resist deformation during transport, and remain durable through repeated handling in distribution. The manufacturer datasheet positioning states that the material conforms to natural‑resin designation IS 7328‑3‑BB‑HXDA of IS 7328:2020 for polyethylene raw material used in moulding and extrusion for blow‑moulded products.

Technical insights

• Melt Flow Index (I2) ~0.35 g/10 min (190°C/2.16 kg): A medium‑flow blow‑moulding MFI that supports stable parison control for larger, thicker‑wall containers while still offering practical processing on standard blow‑moulding lines.
• Density ~0.963 g/cm³: Higher density generally correlates with higher stiffness—helpful for stackability and dimensional stability in medium‑size jerrycans.
• Tensile strength at yield ~280 kg/cm² & elongation at yield ~9%: Indicates a strength‑forward resin with controlled ductility—supporting rigid packs that still tolerate handling stresses.
• Flexural modulus ~12000 kg/cm²: A key indicator of rigidity; higher modulus supports better top‑load performance and reduced paneling in larger containers.
• Izod impact strength ~350 J/m: Suggests strong toughness for drops and knocks during filling, warehousing and transport.
• Shore D hardness ~67: A firmer surface feel that supports scuff resistance and handling durability.
• ESCR (10% Igepal) >24 hours: A stress‑crack resistance reference point for typical packaging exposures; always validate against your formulation, wall thickness and design stress points.
• Vicat softening point ~125°C: Useful for understanding heat resistance expectations (e.g., warm storage, transport conditions, and general thermal stability).

Applications

Edible‑oil jerrycans and cans (5–15 L): B63A003 is positioned for blow‑moulded edible‑oil containers where stiffness and stackability are critical. The high‑stiffness profile helps packs stay upright and resist crushing in stacked storage and long‑distance logistics. Ghee and vanaspati containers: For semi‑solid foodstuffs and ghee‑type products, converters often prioritize rigidity, toughness, and dimensional stability to prevent deformation during handling and to maintain consistent pack appearance on shelf. General medium‑size foodstuff containers: Where a manufacturer needs a high‑stiffness HDPE blow‑moulding grade for medium‑volume packs, B63A003 is used to balance processability with container strength—subject to the converter’s compliance validation for the intended food‑contact application.

Comparable alternatives

• GAIL G‑Lex B63A003N: If your application requires UV stabilization (e.g., longer outdoor storage or UV exposure in the supply chain), the “N” variant is typically evaluated. Confirm the exact positioning and typical values on the corresponding datasheet.
• GAIL G‑Lex B52A003 / B52A003N (smaller container class): Often positioned for smaller containers up to ~5 L. Compared with B52A003‑class grades, B63A003’s higher density (~0.963 vs ~0.954) and higher flexural modulus (~12000 vs ~10000 kg/cm²) support better stack stiffness for medium‑size packs.
• Other HDPE blow‑moulding grades in India: Comparable grades should be screened by matching the full decision cluster—MFI (~0.35), density (~0.963), stiffness (flexural modulus), impact, ESCR, and the target container size range. Direct equivalence should not be assumed without mould trials and end‑use validation.

Common search variants

Also searched as: Gail B63A003 HDPE, G‑Lex B63A003 blow moulding, B63A003 dana, HDPE jerrycan grade. Common misspellings: B63AOO3, B63A003N/A, Glex B63A003.

Gail HDPE G‑Lex B63A003N is a UV‑stabilized high‑density polyethylene (HDPE) blow‑moulding grade from GAIL (India) Limited. It is recommended for medium‑size containers up to about 15 litres, mainly for foodstuffs such as edible oil and ghee, where manufacturers need an optimum balance of toughness, stiffness, stackability, and processability. In real‑world blow moulding, B63A003N is used for rigid, stack‑stable jerrycans, cans and bottles in the 5–15 L range. The grade is positioned to help converters make containers that withstand repeated filling, stack loads in storage, and shipping shocks, while maintaining shape and handling durability. The “N” variant adds UV stabilization, which supports improved robustness during handling and storage versus the non‑UV grade. As per the manufacturer positioning, B63A003/B63A003N conforms to natural‑resin designation IS 7328‑3‑BB‑HXDA of IS 7328:2020 for polyethylene used in moulding/extrusion for blow‑moulded products.

Technical insights

• Melt Flow Index (I2) ~0.35 g/10 min (190°C/2.16 kg): Indicates a medium‑flow blow‑moulding grade suited to thicker‑wall, medium‑size containers.
• Density ~0.963 g/cm³: A higher density HDPE typically supports higher stiffness—important for stackability and dimensional stability in 10–15 L packs.
• Tensile strength at yield ~280 kg/cm² & elongation at yield ~9%: Suggests a strength‑forward resin with controlled ductility—supporting rigid packs that still tolerate handling stress.
• Flexural modulus ~12000 kg/cm²: A key stiffness metric; higher modulus supports better top‑load performance and reduced paneling in larger blow‑moulded containers.
• Izod impact strength ~350 J/m: Supports toughness for drops and knocks during filling, warehousing and transport.
• Shore D hardness ~67: A firmer surface feel that supports scuff resistance and handling durability.
• ESCR (10% Igepal) >24 hours: A reference point for stress‑crack resistance; validate against your formulation, wall thickness, and high‑stress design zones (base/handle/neck).
• Vicat softening point ~125°C: Helps set expectations for thermal performance during storage and handling in warm supply chains.

Applications

Edible‑oil jerrycans and cans (5–15 L): B63A003N is positioned for HDPE blow‑moulded edible‑oil containers where high stiffness and stackability matter. The resin profile supports containers that resist crushing in stacked storage and maintain shape through distribution. Ghee and vanaspati containers: For ghee‑type and vanaspati packaging, converters often prioritize rigidity, toughness, and dimensional stability to prevent deformation during handling and to keep pack appearance consistent on shelf. Medium‑size foodstuff containers requiring UV stability: When the supply chain includes exposure to light (storage yards, transport, or longer warehousing), the UV‑stabilized positioning of B63A003N can be a deciding factor—alongside the grade’s stiffness and processability.

Comparable alternatives

• GAIL G‑Lex B63A003 (non‑UV): Closest alternative when UV stabilization is not required. B63A003N is typically evaluated when UV stability is desired for handling/storage conditions.
• GAIL G‑Lex B52A003 / B52A003N (smaller container class): Often positioned for smaller containers up to ~5 L. Compared with B52A003‑class grades, B63A003N’s higher density (~0.963) and higher stiffness profile are aligned with medium‑size, stack‑stiff jerrycans.
• Other HDPE blow‑moulding grades in India: Comparable grades should be screened by matching the decision cluster—MFI (~0.35), density (~0.963), stiffness (flexural modulus), impact, ESCR, and target container size. Direct equivalence should not be assumed without mould trials and end‑use validation.

Common search variants

Also searched as: Gail B63A003N HDPE, G‑Lex B63A003N blow moulding, B63A003N dana, HDPE jerrycan grade. Common misspellings: B63AOO3N, B63A003 N, Glex B63A003N.

Gail HDPE G‑Lex F55HM0003 (and the related F55HM0003N) is a high‑density polyethylene (HDPE) blown‑film grade from GAIL (India) Limited engineered for thin‑gauge, high‑strength film. GAIL positions this resin as a high molecular weight HDPE with a bimodal molecular‑weight distribution, designed to deliver a strong balance of mechanical robustness and processing stability on blown‑film lines. In practical converting terms, F55HM0003 is chosen when film producers need high load‑carrying capacity, puncture/tear resistance, and stable drawdown for bag and liner production. The combination of high strength and drawdownability helps reduce film breaks, supports gauge control, and enables downgauging in applications where performance matters more than ultra‑high clarity. GAIL manufactures the G‑Lex HDPE family using CX slurry process technology (often referenced as the G‑Lex platform), which is commonly associated in GAIL’s product literature with strength, impact performance, and processability. The grade is supplied as natural‑colour pellets, typically in 25 kg woven sacks, with standard storage guidance: keep material dry, store below 50 °C, and protect from direct sunlight/UV during storage.

Technical insights

• Melt Flow Index (I2, 190 °C/2.16 kg): 0.09 g/10 min (typical): Very low MFI indicates high molecular weight, which generally supports higher melt strength and toughness in film—useful for thin‑gauge bags that must carry load without tearing.
• Density (23 °C): 0.955 g/cm³ (typical): A higher HDPE density supports stiffness and strength, which helps bags feel “crisp” and improves load-bearing performance versus lower-density polyethylenes.
• Bimodal molecular‑weight distribution: Typically used to combine processability with mechanical performance—helping film converters achieve stable extrusion while maintaining strength and puncture resistance.
• Thin‑gauge drawdownability (positioning): GAIL highlights drawdownability as a key benefit; in production this usually translates to improved gauge stability and fewer breaks when running thinner films.
• Conformance identifier (as stated): Conforms to natural‑resin designation IS 7328‑3B‑FBE‑FXDA of IS 7328:2020 for film-type products.
• Mechanical property cluster: The full datasheet family references mechanical properties for evaluation; where specific tensile/impact numbers are not available in the visible excerpt, treat them as available in the official GAIL datasheet and confirm with the latest COA/TDS for your lot.

Applications

Carry bags and shopping bags (thin‑gauge, high‑strength): F55HM0003 is commonly specified for retail carry bags and shopping bags where converters want higher strength at lower gauge. It suits applications where bag failure (handle tear, puncture, split) creates customer complaints and returns. Grocery bags and trash bags: The grade is positioned for grocery and trash bag production where toughness and tear resistance matter. Film producers typically use HM HDPE grades like this to improve bag integrity under variable loading and handling. Industrial liners and heavy‑duty packaging film: For industrial liners and packaging where puncture and tear resistance are critical, F55HM0003’s high molecular weight profile is relevant—especially when downgauging is a production target without sacrificing performance.

Comparable alternatives

Comparable HDPE film grades exist, but they are not automatically interchangeable—especially when MFI is very low and the grade is positioned as HM blown‑film.

• F55HM0003N: Often treated as the closest comparable within the same family (natural variants). Substitution should still be validated against the latest manufacturer documentation and availability.
• GAIL E45A003 (higher MFI film grade, commonly used for blends): Typically positioned for film applications with a much higher MFI (often used in blends with LD/LLDPE). Compared to F55HM0003, it may process differently and may not deliver the same HM thin‑gauge strength profile.

Procurement rule of thumb: treat “equivalence” as unconfirmed unless you match (1) MFI, (2) density, (3) intended film application window (thin‑gauge HM vs general film/blends), and (4) the exact IS 7328 designation and manufacturer positioning in the datasheets.

Common search variants

Also searched as: HDPE HM blown film granules, carry bag HDPE dana, shopping bag HDPE grade, industrial liner HDPE resin. Common variants/misspellings: F55HM003, F55HM0003N, G Lex F55HM0003, GAIL F55HM0003 HDPE.

Gail HDPE G‑Lex F55HM0003N is a high‑density polyethylene (HDPE) blown‑film resin from GAIL (India) Limited engineered for thin‑gauge, high‑strength film. It is positioned as a high molecular weight grade with a bimodal molecular‑weight distribution, designed to combine excellent mechanical performance with better processability on blown‑film extrusion lines. This “N” variant is commonly referenced in the market as the UV‑stabilized option within the F55HM0003 family, making it relevant for converters who expect outdoor storage/handling of film rolls, printed film, or finished bags before dispatch. In production, the value proposition is straightforward: high strength + strong drawdownability, enabling converters to run thinner gauges with fewer breaks while maintaining load‑carrying performance. GAIL’s G‑Lex HDPE grades are associated with CX slurry process technology, and F55HM0003N is supplied as natural/off‑white pellets, typically packed in 25 kg woven sacks. Standard resin handling applies; keep material dry, store below 50 °C, and protect from direct sunlight/UV during storage.

Technical insights

• Melt Flow Index (I2, 190 °C/2.16 kg): 0.09 g/10 min (typical): Very low MFI indicates high molecular weight, which generally supports toughness, melt strength, and resistance to tearing/puncture in thin films.
• Density (23 °C): 0.955 g/cm³ (typical): Higher HDPE density supports stiffness and strength, often preferred for crisp, strong bag structures and heavy‑duty liners.
• Bimodal molecular‑weight distribution: Typically used to balance processability (stable extrusion and drawdown) with mechanical performance (strength and toughness).
• Drawdownability (positioning): The grade is positioned for excellent drawdown; for converters, this usually means better gauge stability and fewer line interruptions when running thin‑gauge film.
• UV stabilization (variant positioning): UV stabilization helps reduce degradation risk during outdoor exposure in storage/handling stages, supporting more consistent bag performance.
• Conformance identifier (as stated): Conforms to natural‑resin designation IS 7328‑3B‑FBE‑FXDA of IS 7328:2020 for film-type products.
• Mechanical property cluster: Where specific tensile/impact values are not visible in the accessible datasheet excerpt, treat them as available in the official GAIL datasheet/COA and confirm for your lot and test conditions.

Applications

Thin‑gauge carry bags and shopping bags: F55HM0003N is used for blown‑film production where bag makers want higher strength at lower gauge. It fits retail packaging where puncture/tear failures create customer complaints and rework. Grocery bags, trash bags, and daily‑use utility bags: The grade is positioned for bags that face variable loading and handling. HM HDPE film grades are typically chosen to improve toughness and reduce splitting in thin films. Industrial liners and heavy‑duty packaging film: For industrial liners and protective packaging, the combination of high molecular weight and higher density supports puncture resistance and stiffness. UV stabilization can be useful when liners or film rolls are stored or transported in outdoor conditions.

Comparable alternatives

Comparable HDPE blown‑film grades exist, but direct substitution should be validated with datasheets and trials because HM grades can behave differently on blown‑film lines.

• GAIL F55HM0003 (non‑UV variant family): Often treated as the closest alternative when UV stabilization is not required. If your supply chain includes outdoor exposure, F55HM0003N is typically preferred.
• GAIL E45A003 (higher MFI film grade, often used in blends): Typically positioned for general film/blend applications with higher MFI. Compared to F55HM0003N, it may offer easier flow but may not deliver the same HM thin‑gauge strength and drawdown profile.

Procurement takeaway: treat “equivalent grade” claims as unverified unless you match (1) MFI, (2) density, (3) intended use (HM thin‑gauge bags/liners), and (4) the exact IS 7328 designation and manufacturer positioning.

Common search variants

Also searched as: HDPE HM blown film granules, UV stabilized HDPE film grade, carry bag HDPE dana, industrial liner HDPE resin. Common variants/misspellings: F55HM003N, F55HM0003 NA, G Lex F55HM0003N, GAIL F55HM0003N HDPE.
